Jun 15, 2014

Tie rods and Steering track rods ends replaced

One of the things I still had to do was replacing the tie rods and steering track rod ends. When I checked their ball joints when I was rebuilding the front axle they felt ok., no measurable play. But after driving the Amazon for a couple of 100 miles I got the idea the steering wheel wasn't connected at all... aquaplaning when it hasn't rained a drop for weeks... excessive play and getting worse every mile.

The right way to check the ball joints of the rods is to get big pliers and grab the joint; if they're ok it isn't possible to press the bolt in. I must admit the first time I checked them I did it with my bare hands, no brainwave, no pliers.. stupid me....
I checked the ball joints of the rods again and there was a ridiculous amount of play. No need for pliers this time, the weight of an ant was enough to show the play...
When I checked them the first time they were probably filled with rust and old grease giving the same feel as a new one.

Exessive play, most obvious around 54 seconds

 Time for new rods!

I started with the Steering rod . I used a ball joint splitter to get the track rod ends out of the arms. Then I measured the overall length so the toe in would stay the same (well...I hoped it would stay the same..).

Left steering track rod end Volvo Amazon
Left steering track rod end Volvo 122S

Steering rod Volvo 122S
Steering rod Volvo Amazon

Steering rod removed Volvo 122S
Steering rod removed Volvo 122S



The steering track rod ends are different on each side. On the left hand side (seen from sitting in the car) the thread is opposite of what you are used to. The right one has a normal thread. This will give you the possibility to turn the steering rod and thus in- or decrease the toe-in. Turning the steering rod in the same direction as the wheels when driving forward will  increase the toe-in, turning the steering rod the other way will decrease the toe in.

Steering track rods old and new Volvo 122S
Steering track rods old and new Volvo 122S


Different threads left and right steering track rod ends Vovlo Amazon
Different threads left and right steering track rod ends

After replacing the steering rod ends I started disconnecting the left tie rod. Again using the ball joint splitter.
This replacement  is pretty straight forward and won't take long. I protected the new rims with some rags while splitting the joint.

Splitting the tie rod joints Volvo 122S
Splitting the tie rod joints

Protecting the GT rims while splitting the tie rod joint Volvo 122S
Protecting the GT rims while splitting the tie rod joint

With the tie rods you also have a left (L) and a right (R) side one.

Left (L) and (R) tie rod Volvo 122S
Left (L) and (R) tie rod Volvo 122S

As can be seen in the previous pics, the castle nuts with split pen were replaced with nyloc nuts. When I tried to tighten the nuts the "bolt" from the joint started to turn, making it impossible to tighten the nut. So I put a jack underneath the joint and pushed it a bit (not too pressure!) so I could tighten the nyloc nuts with a 37 Newton meter torque.


Pushing the rod in the pitman arm Volvo Amazon
Pushing the rod in the arm

After all the new steering parts were fitted I drove the Volvo to a tyre centre to get a wheel alignment. It's best to do this straight away, otherwise you need new tyres within a couple of thousand miles.

At a wheel alignment they will check and adjust the Camber, Caster and Toe-in.
Camber is angle between the vertical axis of the wheels used for steering and the vertical axis of the car when viewed from front.

Camber
Camber

Caster is the angle created by the steering pivot point from the front to back of the vehicle. Caster is positive if the line is angled forward, and negative if backward.

Caster
Caster


Toe represents the angle derived from pointing the tires inward or outward from a top-down view – much like looking down at your toes and angling them inward or outward.

Toe-in
Toe-in
In the Volvo Greenbooks and Haynes you can find the following specifications:

Camber: 0.5 degrees positive
Caster:  0 - 0.5 degrees
Toe in: 0 -0.4 mm

However to get a better grip I choose for the following specs:

Camber: 0.4 degrees negative
Caster:  1.0 degrees
Toe in: 0.35 mm

Camber and Caster adjusted with shims Volvo Amazon
Camber and Caster adjusted with shims

Toe-in adjusted by turning steering rod Volvo Amazon
Toe-in adjusted by turning steering rod
After the wheel alignment it felt like driving a new car home. Wheel alignment is worth every cent and you'll also save your tyres and rod joints.

Jun 13, 2014

GT wheels Volvo 122S

It's a matter of taste but I've always loved the GT rims on the Volvo 122S. So when the Amazon was almost ready I started the hunt for 4 steel GT wheels. Second hand ones are  hard to find and expensive. Luckily there are reproduction GT wheels for sale. But be careful! There are good and bad repro GT wheels.

You can recognise the good ones: they will have a TUV label. This label will assure the quality of the rims. The ones I bought were made in Denmark.

TUV-label GT wheels Volvo 122S

When I got the GT wheels I filled the seams with clear coat to keep the rust away. I also treated the surface with A-Glaze for extra protection.

New Volvo GT rims Volvo 122S
New Volvo GT rims Volvo 122S

New Volvo GT rim Volvo 122S
New Volvo GT rim Volvo 122S

 Volvo GT wheel Volvo Amazon
 Volvo GT wheel Volvo 122S

 Volvo GT wheel Volvo 122S 5.5 inch
 Volvo GT wheel Volvo 122S 5.5 inch

 Volvo GT wheel Volvo 122S

 Volvo GT wheel Volvo 122S

 Volvo GT wheel Volvo 122S


The Volvo GT wheels have the following specifications:
Type:  613014
Size: 15 x 5.5
Offset:  14 mm
Holes: 5
Colour:  Silver

Tyre choice: Kuhmo KH17  195/65/R15 91H

5.5 inch GT wheel Volvo 122S
5.5 inch GT wheel Volvo 122S

5.5 inch GT wheel Volvo 122S
Volvo 122S on the beach
